Hidraulikus targonca kiegészítők üvegkezelő

Alkalmazás

---

This glass handler had the span ranging from 1900mm to 2610mm, and was at safety level III with net weight of 360kg and loading capacity of 2500kg, suitable for attaching on 3-4.5t forklifts. Integrating the functions of clamping and side shifting,this LGH25G-B1 glass handler could handle and stack the glasses safety and effectively, which could be used by manufactures and dealers of glasses.

Leírás

---

jegyzet

---

1. Obtain the actual capacity of the forklift and attachments from the forklift manufacturer,
2. Please contact the sales from HUAMAI

Gyors részletek

---

Származási hely: Fujian, Kína (szárazföld)
Márkanév: HUAMAI
Model Number: LGH25G-B1
Product Name: Glass Handler
Forlift Tonnage: 3-4.5T
Szerelési osztály: III
Total Reach: 1900~2610mm
Total Sideshift: +/-100mm
Over Width: 1000mm
Over Height: 680mm
Effective Tickness: 166mm
Horizontal Center of Gravity CGH: 890mm
MOQ: 1SET

---

[Bevezetés]

HUAMAI hydraulic glass handler had the span ranging from 1900mm to 2610 mm, and was at safety level III with net weight of 360 kg and loading capacity of 2500 kg, suitable for attaching on 3-4.5t forklifts. Integrating the functions of clamping and side shifting, this HUAMAI-25G-B1 glass handler could handle and stack the glasses safety and effectively, which could be used by manufactures and dealers of glasses.

Leírás

Modell	Kapacitás@ Terhelési központ (Kg @ mm)	Targonca Tonnage	Beépítési Osztály	Teljes Reach (Mm)	Teljes Side shift (Mm)	Over Szélesség (Mm)	Over Magasság (Mm)	Hatékony Vastagság (Mm)	Vízszintes Budapest központja súly (Mm)
HUAMAI-25G -B1	2500@1100	3-4.5T	III	1900-2610	+/-100	1000	680	166	890
